Capacity: 6 - 9 ton
CONTAINER HANDLER
Container Handler
The X Series Empty Container Handler 9.0t from HANGCHA is a highly efficient and reliable machine designed specifically for handling empty containers. Capable of lifting loads of up to 9.0 tons, it is engineered to meet the operational demands of ports and container terminals. Known as an Empty Container Handler or Empty Stacker, this material handling equipment excels in lifting, loading, moving, and unloading containers, making it an indispensable tool in the port industry for its exceptional efficiency and performance.
Model & Specifications
| Model | Product Type | Load Capacity | Lift Height | Service Weight | Dimensions(L*W*H) | Turning Radius | Gradeability | Travel Speed | Battery Voltage Std |
|---|---|---|---|---|---|---|---|---|---|
| 6-7t | IC - Trucks | 6,000~7,000kg | 0~12607mm | 23900~25300kg | 5432* 1878* 1940mm | 4750mm | 20% | 29km/h | / |
| 9t | IC - Trucks | 9,000kg | 0~21700mm | 39,800~41,000kg | 6850* 4120* 4600mm | 6000mm | 22% | 26km/h | / |
